Black Chrome Combination Non-Reversible Ratcheting Wrench 5/16 Inch - Spline - Proto®
- Item Code: JSCR10
- Brand: Proto
- Unit Size: 1
Description
Fractional spline wrenches can be used on fractional 4, 6, 12 point, spline and Torx® fasteners.
Box end is countersunk for easy application to the fastener.
Spline design was created for use with specialty spline bolts which are used when weight and size of bolt heads must be minimized.
Spline design enables the wrench to contact conventional fasteners away from the corners, which applies force over a larger area, reducing risk of fastener scoring and helps prevent rounding of the corners and other fasteners damage that could lead to Foreign Object Damage (FOD).
The high contact surface area which is away from fastener points enables turning of highly rounded fasteners.
Anti-Slip Design (ASD) open end.
Black chrome finish is corrosion resistant and visually distinctive.
Features
Back To Top- Fractional spline wrenches can be used on fractional 4, 6, 12 point, spline and Torx® fasteners.
- Box end is countersunk for easy application to the fastener.
- Spline design was created for use with specialty spline bolts which are used when weight and size of bolt heads must be minimized.
- Spline design enables the wrench to contact conventional fasteners away from the corners, which applies force over a larger area, reducing risk of fastener scoring and helps prevent rounding of the corners and other fasteners damage that could lead to Foreign Object Damage (FOD).
- The high contact surface area which is away from fastener points enables turning of highly rounded fasteners.
- Anti-Slip Design (ASD) open end.
- Black chrome finish is corrosion resistant and visually distinctive.
Tech Specs
Back To Top| UPC Code | 662679972233 |
|---|---|
| Item Height [in] | 0.200 |
| Box Quantity | 10 |
| Carton Width [in] | 7.200 |
| Carton Length [in] | 10.900 |
| Head Thickness 1 [in] | 1/8 |
| Item Length [in] | 5.500 |
| Item Width [in] | 0.700 |
| Outside Head Width 1 [in] | 11/16 |
| Outside Head Width 2 [in] | 21/32 |
| Point Size | Spline |
| Carton Height [in] | 5.500 |
| Harmonization Code | 8204110030 |
| Head Thickness 2 [in] | 1/8 |
| Item Quantity | 1 |
| Item Weight [lbs] | 0.060 |
| Box Height [in] | 2.000 |
| Brand | Proto |
| Carton Quantity | 100 |
| Box Weight [lbs] | 0.750 |
| Carton Weight [lbs] | 8.040 |
| Size [in] | 5/16 |
| Box Length [in] | 6.400 |
| Country of Origin | Taiwan |
| Overall Length [in] | 5-1/2 |
| Box Width [in] | 2.000 |
| Finish | Black Chrome |
| Length [in] | 5-1/2 |
