Black Chrome Combination Non-Reversible Ratcheting Wrench 3/8 Inch - Spline - Proto®
- Item Code: JSCR12
- Brand: Proto
- Unit Size: 1
Description
Fractional spline wrenches can be used on fractional 4, 6, 12 point, spline and Torx® fasteners.
Box end is countersunk for easy application to the fastener.
Spline design was created for use with specialty spline bolts which are used when weight and size of bolt heads must be minimized.
Spline design enables the wrench to contact conventional fasteners away from the corners, which applies force over a larger area, reducing risk of fastener scoring and helps prevent rounding of the corners and other fasteners damage that could lead to Foreign Object Damage (FOD).
The high contact surface area which is away from fastener points enables turning of highly rounded fasteners.
Anti-Slip Design (ASD) open end.
Black chrome finish is corrosion resistant and visually distinctive.
Features
Back To Top- Fractional spline wrenches can be used on fractional 4, 6, 12 point, spline and Torx® fasteners.
- Box end is countersunk for easy application to the fastener.
- Spline design was created for use with specialty spline bolts which are used when weight and size of bolt heads must be minimized.
- Spline design enables the wrench to contact conventional fasteners away from the corners, which applies force over a larger area, reducing risk of fastener scoring and helps prevent rounding of the corners and other fasteners damage that could lead to Foreign Object Damage (FOD).
- The high contact surface area which is away from fastener points enables turning of highly rounded fasteners.
- Anti-Slip Design (ASD) open end.
- Black chrome finish is corrosion resistant and visually distinctive.
Tech Specs
Back To Top| Carton Weight [lbs] | 12.200 |
|---|---|
| UPC Code | 662679972257 |
| Carton Length [in] | 8.100 |
| Country of Origin | Taiwan |
| Item Length [in] | 6.200 |
| Box Width [in] | 2.000 |
| Carton Height [in] | 9.500 |
| Finish | Black Chrome |
| Harmonization Code | 8204110030 |
| Head Thickness 2 [in] | 1/8 |
| Item Quantity | 1 |
| Outside Head Width 2 [in] | 25/32 |
| Box Height [in] | 2.000 |
| Brand | Proto |
| Outside Head Width 1 [in] | 13/16 |
| Size [in] | 3/8 |
| Box Quantity | 10 |
| Carton Width [in] | 6.100 |
| Item Height [in] | 0.300 |
| Item Weight [lbs] | 0.110 |
| Length [in] | 6-1/4 |
| Head Thickness 1 [in] | 1/8 |
| Overall Length [in] | 6-1/4 |
| Item Width [in] | 0.800 |
| Point Size | Spline |
| Box Length [in] | 6.800 |
| Box Weight [lbs] | 1.150 |
| Carton Quantity | 100 |
