Black Chrome Combination Non-Reversible Ratcheting Wrench 5/8 Inch - Spline - Proto®
- Item Code: JSCR20
- Brand: Proto
- Unit Size: 1
Description
Fractional spline wrenches can be used on fractional 4, 6, 12 point, spline and Torx® fasteners.
Box end is countersunk for easy application to the fastener.
Spline design was created for use with specialty spline bolts which are used when weight and size of bolt heads must be minimized.
Spline design enables the wrench to contact conventional fasteners away from the corners, which applies force over a larger area, reducing risk of fastener scoring and helps prevent rounding of the corners and other fasteners damage that could lead to Foreign Object Damage (FOD).
The high contact surface area which is away from fastener points enables turning of highly rounded fasteners.
Anti-Slip Design (ASD) open end.
Black chrome finish is corrosion resistant and visually distinctive.
Features
Back To Top- Fractional spline wrenches can be used on fractional 4, 6, 12 point, spline and Torx® fasteners.
- Box end is countersunk for easy application to the fastener.
- Spline design was created for use with specialty spline bolts which are used when weight and size of bolt heads must be minimized.
- Spline design enables the wrench to contact conventional fasteners away from the corners, which applies force over a larger area, reducing risk of fastener scoring and helps prevent rounding of the corners and other fasteners damage that could lead to Foreign Object Damage (FOD).
- The high contact surface area which is away from fastener points enables turning of highly rounded fasteners.
- Anti-Slip Design (ASD) open end.
- Black chrome finish is corrosion resistant and visually distinctive.
Tech Specs
Back To Top| Carton Height [in] | 13.100 |
|---|---|
| Carton Weight [lbs] | 35.300 |
| UPC Code | 662679972295 |
| Finish | Black Chrome |
| Item Length [in] | 8.200 |
| Length [in] | 8-3/16 |
| Point Size | Spline |
| Box Width [in] | 4.200 |
| Brand | Proto |
| Carton Width [in] | 9.200 |
| Outside Head Width 1 [in] | 1-5/16 |
| Box Quantity | 10 |
| Box Weight [lbs] | 4.300 |
| Head Thickness 2 [in] | 3/16 |
| Item Weight [lbs] | 0.320 |
| Item Width [in] | 1.300 |
| Carton Quantity | 100 |
| Head Thickness 1 [in] | 3/16 |
| Item Height [in] | 0.400 |
| Box Height [in] | 2.400 |
| Box Length [in] | 10.500 |
| Country of Origin | Taiwan |
| Outside Head Width 2 [in] | 1-3/16 |
| Overall Length [in] | 8-3/16 |
| Size [in] | 5/8 |
| Carton Length [in] | 11.200 |
| Harmonization Code | 8204110030 |
| Item Quantity | 1 |
