Black Chrome Combination Non-Reversible Ratcheting Wrench 11/16 Inch - Spline - Proto®
- Item Code: JSCR22
- Brand: Proto
- Unit Size: 1
Description
Fractional spline wrenches can be used on fractional 4, 6, 12 point, spline and Torx® fasteners.
Box end is countersunk for easy application to the fastener.
Spline design was created for use with specialty spline bolts which are used when weight and size of bolt heads must be minimized.
Spline design enables the wrench to contact conventional fasteners away from the corners, which applies force over a larger area, reducing risk of fastener scoring and helps prevent rounding of the corners and other fasteners damage that could lead to Foreign Object Damage (FOD).
The high contact surface area which is away from fastener points enables turning of highly rounded fasteners.
Anti-Slip Design (ASD) open end.
Black chrome finish is corrosion resistant and visually distinctive.
Features
Back To Top- Fractional spline wrenches can be used on fractional 4, 6, 12 point, spline and Torx® fasteners.
- Box end is countersunk for easy application to the fastener.
- Spline design was created for use with specialty spline bolts which are used when weight and size of bolt heads must be minimized.
- Spline design enables the wrench to contact conventional fasteners away from the corners, which applies force over a larger area, reducing risk of fastener scoring and helps prevent rounding of the corners and other fasteners damage that could lead to Foreign Object Damage (FOD).
- The high contact surface area which is away from fastener points enables turning of highly rounded fasteners.
- Anti-Slip Design (ASD) open end.
- Black chrome finish is corrosion resistant and visually distinctive.
Tech Specs
Back To Top| Carton Weight [lbs] | 38.590 |
|---|---|
| UPC Code | 662679972301 |
| Brand | Proto |
| Item Width [in] | 1.400 |
| Box Length [in] | 10.000 |
| Box Width [in] | 3.500 |
| Carton Length [in] | 14.800 |
| Finish | Black Chrome |
| Outside Head Width 1 [in] | 1-3/8 |
| Harmonization Code | 8204110030 |
| Item Quantity | 1 |
| Overall Length [in] | 8-7/8 |
| Item Height [in] | 0.400 |
| Item Weight [lbs] | 0.370 |
| Outside Head Width 2 [in] | 1-1/4 |
| Size [in] | 11/16 |
| Box Weight [lbs] | 3.680 |
| Length [in] | 8-7/8 |
| Point Size | Spline |
| Box Height [in] | 2.800 |
| Carton Quantity | 100 |
| Carton Width [in] | 11.000 |
| Head Thickness 1 [in] | 3/16 |
| Box Quantity | 10 |
| Carton Height [in] | 8.200 |
| Country of Origin | Taiwan |
| Head Thickness 2 [in] | 3/16 |
| Item Length [in] | 8.900 |
