Black Chrome Combination Non-Reversible Ratcheting Wrench 15/16 Inch - Spline - Proto®
- Item Code: JSCR30
- Brand: Proto
- Unit Size: 1
Description
Fractional spline wrenches can be used on fractional 4, 6, 12 point, spline and Torx® fasteners.
Box end is countersunk for easy application to the fastener.
Spline design was created for use with specialty spline bolts which are used when weight and size of bolt heads must be minimized.
Spline design enables the wrench to contact conventional fasteners away from the corners, which applies force over a larger area, reducing risk of fastener scoring and helps prevent rounding of the corners and other fasteners damage that could lead to Foreign Object Damage (FOD).
The high contact surface area which is away from fastener points enables turning of highly rounded fasteners.
Anti-Slip Design (ASD) open end.
Black chrome finish is corrosion resistant and visually distinctive.
Features
Back To Top- Fractional spline wrenches can be used on fractional 4, 6, 12 point, spline and Torx® fasteners.
- Box end is countersunk for easy application to the fastener.
- Spline design was created for use with specialty spline bolts which are used when weight and size of bolt heads must be minimized.
- Spline design enables the wrench to contact conventional fasteners away from the corners, which applies force over a larger area, reducing risk of fastener scoring and helps prevent rounding of the corners and other fasteners damage that could lead to Foreign Object Damage (FOD).
- The high contact surface area which is away from fastener points enables turning of highly rounded fasteners.
- Anti-Slip Design (ASD) open end.
- Black chrome finish is corrosion resistant and visually distinctive.
Tech Specs
Back To Top| Box Weight [lbs] | 5.290 |
|---|---|
| Carton Weight [lbs] | 22.320 |
| UPC Code | 662679972349 |
| Box Width [in] | 3.500 |
| Item Length [in] | 12.700 |
| Item Width [in] | 1.800 |
| Brand | Proto |
| Carton Height [in] | 5.500 |
| Point Size | Spline |
| Overall Length [in] | 12-3/4 |
| Carton Width [in] | 8.000 |
| Country of Origin | Taiwan |
| Length [in] | 12-3/4 |
| Outside Head Width 1 [in] | 2-1/16 |
| Finish | Black Chrome |
| Head Thickness 2 [in] | 1/4 |
| Item Height [in] | 0.500 |
| Box Height [in] | 2.200 |
| Carton Length [in] | 14.200 |
| Size [in] | 15/16 |
| Harmonization Code | 8204110030 |
| Item Quantity | 1 |
| Box Length [in] | 13.000 |
| Box Quantity | 5 |
| Carton Quantity | 20 |
| Head Thickness 1 [in] | 1/4 |
| Item Weight [lbs] | 1.050 |
| Outside Head Width 2 [in] | 1-13/16 |
