Black Chrome Combination Non-Reversible Ratcheting Wrench 15 mm - Spline - Proto®
- Item Code: JSCRM15
- Brand: Proto
- Unit Size: 1
Description
Metric Spline wrenches can be used on metric 4, 6, 12 point, spline and Torx® fasteners.
Box end is countersunk for easy application to the fastener.
Spline design was created for use with specialty spline bolts which are used when weight and size of bolt heads must be minimized.
Spline design enables the wrench to contact conventional fasteners away from the corners, which applies force over a larger area, reducing risk of fastener scoring and helps prevent rounding of the corners and other fasteners damage that could lead to Foreign Object Damage (FOD).
The high contact surface area which is away from fastener points enables turning of highly rounded fasteners.
Anti-Slip Design (ASD) open end.
Black chrome finish is corrosion resistant and visually distinctive.
Features
Back To Top- Metric Spline wrenches can be used on metric 4, 6, 12 point, spline and Torx® fasteners.
- Box end is countersunk for easy application to the fastener.
- Spline design was created for use with specialty spline bolts which are used when weight and size of bolt heads must be minimized.
- Spline design enables the wrench to contact conventional fasteners away from the corners, which applies force over a larger area, reducing risk of fastener scoring and helps prevent rounding of the corners and other fasteners damage that could lead to Foreign Object Damage (FOD).
- The high contact surface area which is away from fastener points enables turning of highly rounded fasteners.
- Anti-Slip Design (ASD) open end.
- Black chrome finish is corrosion resistant and visually distinctive.
Tech Specs
Back To Top| Carton Weight [lbs] | 27.800 |
|---|---|
| UPC Code | 662679972431 |
| Box Width [in] | 2.800 |
| Carton Length [in] | 13.200 |
| Finish | Black Chrome |
| Country of Origin | Taiwan |
| Item Weight [lbs] | 0.270 |
| Length [in] | 7-7/8 |
| Outside Head Width 1 [in] | 1-1/4 |
| Item Length [in] | 7.900 |
| Brand | Proto |
| Carton Quantity | 100 |
| Box Length [in] | 8.100 |
| Outside Head Width 2 [in] | 1-7/64 |
| Box Height [in] | 2.400 |
| Harmonization Code | 8204110030 |
| Head Thickness 1 [in] | 3/16 |
| Item Quantity | 1 |
| Box Quantity | 10 |
| Box Weight [lbs] | 2.670 |
| Carton Height [in] | 7.000 |
| Carton Width [in] | 9.200 |
| Head Thickness 2 [in] | 3/16 |
| Item Width [in] | 1.200 |
| Point Size | Spline |
| Size [mm] | 15 |
| Item Height [in] | 0.300 |
| Overall Length [in] | 7-7/8 |
