Black Chrome Combination Non-Reversible Ratcheting Wrench 17 mm - Spline - Proto®
- Item Code: JSCRM17
- Brand: Proto
- Unit Size: 1
Description
Metric Spline wrenches can be used on metric 4, 6, 12 point, spline and Torx® fasteners.
Box end is countersunk for easy application to the fastener.
Spline design was created for use with specialty spline bolts which are used when weight and size of bolt heads must be minimized.
Spline design enables the wrench to contact conventional fasteners away from the corners, which applies force over a larger area, reducing risk of fastener scoring and helps prevent rounding of the corners and other fasteners damage that could lead to Foreign Object Damage (FOD).
The high contact surface area which is away from fastener points enables turning of highly rounded fasteners.
Anti-Slip Design (ASD) open end.
Black chrome finish is corrosion resistant and visually distinctive.
Features
Back To Top- Metric Spline wrenches can be used on metric 4, 6, 12 point, spline and Torx® fasteners.
- Box end is countersunk for easy application to the fastener.
- Spline design was created for use with specialty spline bolts which are used when weight and size of bolt heads must be minimized.
- Spline design enables the wrench to contact conventional fasteners away from the corners, which applies force over a larger area, reducing risk of fastener scoring and helps prevent rounding of the corners and other fasteners damage that could lead to Foreign Object Damage (FOD).
- The high contact surface area which is away from fastener points enables turning of highly rounded fasteners.
- Anti-Slip Design (ASD) open end.
- Black chrome finish is corrosion resistant and visually distinctive.
Tech Specs
Back To Top| Carton Weight [lbs] | 41.300 |
|---|---|
| UPC Code | 662679972455 |
| Box Weight [lbs] | 4.900 |
| Carton Length [in] | 11.200 |
| Head Thickness 1 [in] | 3/16 |
| Length [in] | 8-7/8 |
| Size [mm] | 17 |
| Box Width [in] | 4.200 |
| Item Height [in] | 0.400 |
| Outside Head Width 2 [in] | 1-1/4 |
| Brand | Proto |
| Carton Width [in] | 9.200 |
| Point Size | Spline |
| Box Height [in] | 2.400 |
| Box Quantity | 10 |
| Country of Origin | Taiwan |
| Harmonization Code | 8204110030 |
| Head Thickness 2 [in] | 3/16 |
| Item Quantity | 1 |
| Finish | Black Chrome |
| Item Length [in] | 8.900 |
| Carton Quantity | 100 |
| Overall Length [in] | 8-7/8 |
| Box Length [in] | 10.500 |
| Carton Height [in] | 13.100 |
| Item Weight [lbs] | 0.400 |
| Item Width [in] | 1.400 |
| Outside Head Width 1 [in] | 1-7/16 |
