Black Chrome Combination Non-Reversible Ratcheting Wrench 19 mm - Spline - Proto®
- Item Code: JSCRM19
- Brand: Proto
- Unit Size: 1
Description
Metric Spline wrenches can be used on metric 4, 6, 12 point, spline and Torx® fasteners.
Box end is countersunk for easy application to the fastener.
Spline design was created for use with specialty spline bolts which are used when weight and size of bolt heads must be minimized.
Spline design enables the wrench to contact conventional fasteners away from the corners, which applies force over a larger area, reducing risk of fastener scoring and helps prevent rounding of the corners and other fasteners damage that could lead to Foreign Object Damage (FOD).
The high contact surface area which is away from fastener points enables turning of highly rounded fasteners.
Anti-Slip Design (ASD) open end.
Black chrome finish is corrosion resistant and visually distinctive.
Features
Back To Top- Metric Spline wrenches can be used on metric 4, 6, 12 point, spline and Torx® fasteners.
- Box end is countersunk for easy application to the fastener.
- Spline design was created for use with specialty spline bolts which are used when weight and size of bolt heads must be minimized.
- Spline design enables the wrench to contact conventional fasteners away from the corners, which applies force over a larger area, reducing risk of fastener scoring and helps prevent rounding of the corners and other fasteners damage that could lead to Foreign Object Damage (FOD).
- The high contact surface area which is away from fastener points enables turning of highly rounded fasteners.
- Anti-Slip Design (ASD) open end.
- Black chrome finish is corrosion resistant and visually distinctive.
Tech Specs
Back To Top| Box Weight [lbs] | 4.870 |
|---|---|
| Carton Weight [lbs] | 49.990 |
| UPC Code | 662679972479 |
| Length [in] | 9-3/4 |
| Box Width [in] | 3.500 |
| Carton Height [in] | 8.500 |
| Finish | Black Chrome |
| Head Thickness 2 [in] | 1/4 |
| Overall Length [in] | 9-3/4 |
| Harmonization Code | 8204110030 |
| Item Height [in] | 0.500 |
| Item Quantity | 1 |
| Item Weight [lbs] | 0.510 |
| Item Width [in] | 1.600 |
| Outside Head Width 1 [in] | 1-9/16 |
| Outside Head Width 2 [in] | 1-21/64 |
| Head Thickness 1 [in] | 1/4 |
| Item Length [in] | 9.800 |
| Carton Quantity | 100 |
| Carton Width [in] | 11.000 |
| Box Height [in] | 2.700 |
| Carton Length [in] | 14.800 |
| Point Size | Spline |
| Size [mm] | 19 |
| Box Length [in] | 10.100 |
| Box Quantity | 10 |
| Brand | Proto |
| Country of Origin | Taiwan |
