Right Hand, 90° Lead Angle, 0.976 Inch Min Bore Diameter, TOGX 06T1.. Boring Cartridge
- Item Code: M03 10011
- Brand: Komet
- Unit Size: 1
Description
M03 00115 Compatible
Tech Specs
Back To Top| Boring Head Compatibility | M03 00115 |
|---|---|
| Minimum Bore Diameter | 24.79mm |
| Mount Bars | Angular |
| Insert Style | TOGX 06T1.. |
| Lead Angle | 90 Degree |
| Complete Insert Compatibility | TOGX 06T102EN-14; TOGX 06T102FN-12; TOGX 06T102TN; TOHX 06T103EL-G06 |
| Cutting Direction | Right Hand |
| Brand | Komet |
| Series | M03Speed |
| Type | Boring Cartridge |
