4 Inch Solid Carbide 8-Flute 120° Included Angle Hexagon Face Mill
- Item Code: M1200HF400Z08S150HN09
- Brand: WIDIA
- Unit Size: 1
Description
Series M120
High-Performance Solid Carbide End Mills
Hard Materials
Features
Back To Top- Non-Center Cutting
- High Feed
Tech Specs
Back To Top| Cutting Diameter | 4 Inch |
|---|---|
| Depth of Cut | 0.0860 Inch |
| Included Angle | 120 Deg |
| Type | Face Mill |
| Lead Angle | 15 Deg |
| Overall Length | 1.7500 Inch |
| Shank Diameter | 1-1/2 Inch |
| Number of Flutes | 8 |
| Direction of Cut | Right Hand |
| Flute Style | Helix |
| Insert Shape | Hexagon |
| Brand | WIDIA |
| Product Name | Indexable Milling Cutters |
| Coolant Through (Yes/No) | Yes |
