3/32 Inch Carbide Long Screw

  • Item Code: MDW00937HGS8
  • Brand: Sumitomo
  • Unit Size: 1

Description

Features Tech Specs

Features

Back To Top
    • Long Tool Life
    • New cutting edge design and special DEX coating provide long tool life in a wide variety of work materials.
    • Stable Chip Evacuation
    • New flute design and wide chip pocket allows for excellent chip management and evacuation.
    • Quiet Cutting & Stable Cutting
    • Stable drilling with minimal vibration even in small machine applications
    • Environmentally Friendly
    • Compatible with MQL (Minimum Quantity Lubrication) Systems.

Tech Specs

Back To Top
Length of Cut 1.0827 Inch
Overall Length Decimal 3.1890"
Brand Sumitomo
Coating/Finish DEX
Product Name Long Drill
Series MDW-HGS8
Coolant Supply Internal
Decimal Size 0.0937"
Metric Size 2.38 mm
Shank Diameter 0.1250 Inch
Material Solid Carbide
Shank Length 2.0472 Inch
Depth Diameter Ratio 8xD
Fractional Size 3/32"
