M2 Thread, Torx Plus Clamping Screw for Indexable Boring Bars
- Item Code: N0056031
- Brand: Komet
- Unit Size: 1
Description
Compatible with Cartridges and Inserts, Kometric and MicroKom Series
Tech Specs
Back To Top| Cartridge Size Compatibility | FZ10; FZ12; UKS6 |
|---|---|
| Screw Length | 0.1929 Inch |
| Complete Insert Compatibility | TOGX 06T102 EN-14; TOGX 06T102 FN-12; TOGX06T102EN-14; TOGX06T102TN; TOHX06T103EL-G06; TOHX06T103ER-G12; TPGX060104FN-12; WOHX03T102EL-G12 |
| Product Type | Clamping Screw |
| Drive Type | Torx Plus |
| Thread Size | M2 |
| Brand | Komet |
| Point Type | Flat |
| Series | Kometric; MicroKom |
| Head Type | Countersunk |
| Screw Type | Clamping Screw |
| Torx Size | TP8 |
| Hardware Compatibility | Cartridge; Insert |
| Indexable Tool Type | Boring Bar |
