WDXT156012-G Grade ACP300 Carbide TiAlN/AlCrN Coated Chipbreaker Milling Insert

  • Item Code: WDXT156012-G ACP300
  • Brand: Sumitomo
  • Unit Size: 1

Description

Tech Specs

Tech Specs

Back To Top
Coating/Finish TiAlN/AlCrN
Corner Radius (Decimal Equiv.) 0.0472
Material Grade C5/C5A/C6
Mfgr's Grade ACP300
Shape Parallelogram
Thickness (Decimal Equiv.) 0.2362
Width (Decimal Equiv.) 0.5984
Insert Size 06
Product Type Milling
Material Solid Carbide
Brand Sumitomo
Chipbreaker G
Cutting Direction Right Hand
Coating Process PVD
Insert Style WDXT
